[CXA-0234] 16 Pin male and female magnetic cable connector for tablet

  • P/N:CXA-0234
  • Magnetic force:4.9 N
  • Convenient connection for automatic adsorption
  • Magnet: NdFeB, permanent magnets
  • Pass Rohs, reach, HF, environmental protection
Inquiry Now

Description

The application of this 16 Pin male and female magnetic cable connector is for tablet and computer connection. CLE is a professional design and manufacture of magnetic connector & magnetic cable connector for customers. CLE Magnetic charging cable ensures compact design,stable connection ,diverse uses and safe protection when detached from devices.

Male Part- – –Specification of 16 Pin male and female magnetic cable connector for tablet

16 Pin male and female magnetic charging cable connector for tablet

Products 16 Pin male and female magnetic cable connector for tablet
 Model No. MMA-0195
Voltage & Current  12 V, 2A
Plastic Core HTN plastic (265°C) UL 94 V-0
Pins Copper,phosphor & beryllium copper, SUS
Gold-plating over Ni
Environment Anti-corrosion,48 hours salt-spray test
Installation Screw fixation,solder,structure limit
Certification RoHs, Reach, HF
Application Tablet
 Downloaded Drawing

 Attention:

1.Magnet use NdFeB material, it’s can keep the magnetic force forever (except high temperature、broken、same pole connection)

2.Magnet exist magnetic field interference

Female Part- – –Specification of 16 Pin male and female magnetic charging cable connector for tablet

16 Pin male and female magnetic charging cable connector for tablet

Products 16 Pin male and female magnetic cable connector for tablet
Model No. CFA-0234
Voltage & Current 5 V, 2.5 A
Magnetic Shape Round , flat
Material PVC, TPE, Silica gel
Environment Anti-corrosion,48 hours salt-spray test
Certification RoHs, Reach, HF
Application  Tablet
Downloaded Drawing

 Attention:

1.Magnet use NdFeB material, it’s can keep the magnetic force forever (except high temperature、broken、same pole connection)

2.Magnet exist magnetic field interference

3.Can design short-circuit protection

CLE Standard

1.Insist on original design, from ID to finish design,open molding and test、production Integration is complete .

CLE Strength

1.R & D team independent design and development capabilities, can be customized with product development; you just have an ID, we will do the left for you,free development,R&D time 3-5 working days.

2.Product projects of multi-program selection, round, square, rectangular, shaped connection with the flexible use of the way to achieve beautiful appearance, saving space, easy plug, magnetic force can achieve 1N to 30N.

3.Connection way:magnet to magnet,magnet to alloy,magnet to Iron sheets and so on,to meet different structure and application, avoid magnetic field interference, use NdFeB magnet, it’s can keep the magnetic force forever.

4.CLE have 6 years experience of R&D magnetic connector, nearly 50 products in  many areas of successful application development experience; products  related to medical, automotive, electrical, consumer electronics, intelligent wear equipment.
